BS EN IEC 62676-4:2025Current
CCTV design and image detail
Agree what each camera is for before it is fitted: detect, observe, recognise or identify.
What BS EN IEC 62676-4 means for you →
Design your system
Designing a CCTV System for Your Site
See what a typical system looks like for offices, industrial sites, retail, schools and construction sites, how we get from survey to certificate, and the paperwork you receive.
System builder
What a typical CCTV system looks like for your site
Pick your type of site to see a typical layout. The numbers on the plan match the list. Every real system is designed from a survey of your own site.
Typical setup: industrial unit or yard
- 1
Bullet or thermal cameras on the perimeter
Detect activity at the fence line, day and night.
- 2
PTZ camera over the yard
Follow vehicles and people across open ground.
- 3
ANPR at the gate
Log every vehicle in and out.
- 4
Monitoring out of hours
Alarms are acted on before damage is done.
Illustrative layout only. Not a real site.
Typical setup: office or reception
- 1
Dome cameras at entrances and reception
Clear faces of everyone coming in.
- 2
Cameras linked to access control
Footage tagged to each door event.
- 3
Car park coverage
Protects staff vehicles and visitors.
Illustrative layout only. Not a real site.
Typical setup: retail store
- 1
High-resolution domes over tills
Evidence-quality footage of transactions.
- 2
Wide-angle coverage of the shop floor
No blind spots between aisles.
- 3
Public view monitor at the door
A visible deterrent as people enter.
Illustrative layout only. Not a real site.
Typical setup: school or academy
- 1
Perimeter and gate cameras
Safeguarding at every entry point.
- 2
Dome cameras in corridors
Covers shared spaces, not classrooms.
- 3
Trust-wide remote viewing
One login across every site.
Illustrative layout only. Not a real site.
Typical setup: construction site
- 1
Rapid-deployment camera towers
Solar or 4G powered, no mains needed.
- 2
AI analytics to cut false alerts
Ignores wildlife and weather.
- 3
Monitored response with audio warning
Intruders are challenged in real time.
Illustrative layout only. Not a real site.
How it works
From survey to certificate
Five steps, each with the paperwork that proves the system was designed and installed properly.
-
Step 1
Site survey
We walk the site with you, agree what each camera needs to do and check cable routes, power and lighting.
You get: Survey notes
-
Step 2
System design
Camera positions, lenses, recording period and storage are designed to suit your site and risks.
You get: Design specification
-
Step 3
Installation
Our own engineers install the system, working around your site with minimal disruption.
You get: “As fitted” specification
-
Step 4
Commissioning
Every camera view, recording setting and remote connection is tested and set to the agreed purpose.
You get: Handover certificate and checklist
-
Step 5
Handover
We show your team how to use the system and leave everything you need for insurers and audits.
You get: System logbook and SSAIB certificate of compliance
At least 30 days of footage, up to 45 where needed
Storage is sized at survey to match the number of cameras and image quality, and confirmed at handover. Remote health checks can then confirm every hour that the system is still recording.
Standards that apply
The standards behind CCTV design
The British Standards and laws we work to, in plain English. Each one links to a summary page with the current edition and the official source.
UK GDPR / DPA 2018Current
UK GDPR and the Data Protection Act 2018 for CCTV and access control
Put up clear signs saying CCTV is in use, who runs it and how to contact them.
What UK GDPR means for you →Got a question about CCTV design?
Ask the Standards Library. Answers come only from our library and quote their sources.
Try one of these:
Answers come only from our standards library and quote their sources. They are general guidance, not advice for a specific building, and are produced automatically, so check the source before relying on them. Please don't include names or personal details in your question.
Editions checked 12 October 2026 by the SPS Technical team.
FAQs
Design and paperwork questions
A design specification, an “as fitted” specification, a CCTV handover certificate and checklist, a system logbook and an SSAIB certificate of compliance.
We set systems to keep at least 30 days of footage, and up to 45 days where a site needs it. Storage is sized at survey to match the number of cameras and image quality, and confirmed at handover.
If your cameras capture people, you are processing personal data under UK GDPR and usually need to pay the ICO data protection fee. We supply compliant signage and advise on retention and privacy at survey.
Usually, yes. Health monitoring works with most leading brands of recorder, so an existing system can normally be connected after a takeover audit.
Ready to plan your system?
Book a free site survey and we'll design a system around your site.
